SHARP TV 20V-L50 NO TV SIGNAL

This problem or trouble was found by me in an electronics forum here in the Philippines. This Sharp tv model 20V-L50 no tv signal with pale red in screen of tv but no sound. But Audio and Video in with good picture and sound. The culprit a transistor with part number C1815. Thanks to this forum ww.elab.ph/forum/index.php?topic=22517.0;nowap and to simatar the technician for posting and sharing this found trouble of this tv. Here is the picture below.





I found this while i searching for schematic of same tv model and in this forum i was member also. I post this to help others too with same problem. Hope it helps.

Painsolv - Pain Relief Treament

If you are tired of taking synthetic drugs that affects our internal organ for pain. You can visit this product here:



http://pro.agorahealth.co.uk/PSV_CED/E963P959/?a=5&o=126905&s=131533&u=572254&l=427475&r=MC&g=0&h=true

SWITCHING TRANSFORMER AND HORIZONTAL TRANSFORMER SELLER



As i research for horizontal driver transformer for my tv to be repair I found this website selling switching transformers, horizontal transformers, smd transformers, line filter, coil. You may visit this link if you are looking for one. The seller i think comes from south korea.  Click here:

http://ohsung76.en.ec21.com/HORIZONTAL_DRIVE_TRANSFORMER--1_3244789.html

CRT and LCD TV Schematic Diagram



A good electronic websites with lots of data regarding smd, stk ic, manual, schematic diagram and books. Visit the link here:http://www.turuta.md/



IC CROSS REFERENCED

All cross-referenced integrated circuits are pin-to-pin, cases and electrical characteristics compatible types and interchangeable on any applications
Link: http://www.turuta.md/ic_cross1.html
	Type	Function	Reference
	AN15525A	CRT vertical deflection output IC	AN15526A
	C0AAAA000035	Dual 2.5W power audio amplifier with stand-by	C0AAAA000036, LA4627
	C0AAAA000036	Dual 2.5W power audio amplifier with stand-by	C0AAAA000035, LA4627
	C0ABBA000021	Single supply operational amplifier	NJM2904M
	C0BBBA000019	Single supply dual comparator	NJM2903M
	C0BBBA000032	Single supply dual comparator	NJM2903V
	C0DAZYY00028	PWM type switching power supply with low noise and low stand-by power	STR-A6059H
	C0DAZZZ00013	Off-line PSU power factor controller	MC33262P
	C0EBB0000024	Voltage detector and system reset	M51957BFP
	C1AA00000359	TV deflection stage with horizontal and vertical deflection bias distortion compensation	TA8859AP
	C1AA00000521	CRT TV/monitors vertical deflection output with bus control support	LA78045
	C1AA00000561	10W class-D power audio amplifier with mute and stand-by	TDA7480
	C1AA00000744	Quadruple 100W BTL class-T power audio amplifier output stage with mute and sleep	TPS4100
	C1AB00002568	Dual 20W BTL class-D power audio amplifier with I2C control and I2S interface	STA323W
	C1AB00002941	Dual 15W BTL class-D power audio amplifier with mute and stand-by	LV4900H
	C1BA00000278	10W BTL (speaker) and 60mW SE (headphone) power audio amplifier with separate stand-by	C1BA00000383, LA4901
	C1BA00000383	10W BTL (speaker) and 60mW SE (headphone) power audio amplifier with separate stand-by	C1BA00000278, LA4901
	C5AA00000107	3-channel convergence correction circuit for projection TV	NTE7181, STK392-040
	C5HABZZ00080	Off-line quasi-resonant flyback switching type voltage regulator for TV SMPS	STR-F6676
	ECG1354	60W power audio amplifier output module	S-60W
	HA11724	VCR video recording/playback preamplifier	KA2984, µPC1534
	IRAMS10UP60B	3-phase inverter motor driver	STK621-140B-E
	IRIS-W6753	Off-line quasi-resonant flyback switching type regulator for TV SMPS	STR-W6753
	IRIS-W6756	Off-line quasi-resonant flyback switching type regulator for TV SMPS	STR-W6756
	KA2984	VCR video recording/playback preamplifier	HA11724, µPC1534
	KA-40W	30W power audio amplifier output module	S-40W
	LA4901	10W BTL (speaker) and 60mW SE (headphone) power audio amplifier with separate stand-by	C1BA00000278, C1BA00000383
	LA78045	CRT TV/monitors vertical deflection output with bus control support	C1AA00000521
	LV4900H	Dual 15W BTL class-D power audio amplifier with mute and stand-by	C1AB00002941
	µPC1534	VCR video recording/playback preamplifier	HA11724, KA2984
	NTE7179	3-channel convergence correction circuit for projection TV	NTE7180, STK392-010, STK392-020
	NTE7180	3-channel convergence correction circuit for projection TV	C5AA00000107, NTE7181, STK392-020, STK392-040
	NTE7181	3-channel convergence correction circuit for projection TV	C5AA00000107, STK392-040
	NTE7224	Quasi-resonant primary switching regulator for TV SMPS	STR-W6735
	S-40W	40W power audio amplifier output module	ECG1354, S-60W
	S-60W	60W power audio amplifier output module	ECG1354
	STA323W	Dual 20W BTL class-D power audio amplifier with I2C control and I2S interface	C1AB00002568
	STK392-010	3-channel convergence correction circuit for projection TV	NTE7179, NTE7180, STK392-020
	STK392-020	3-channel convergence correction circuit for projection TV	C5AA00000107, NTE7180, NTE7181, STK392-040
	STK392-040	3-channel convergence correction circuit for projection TV	C5AA00000107, NTE7181
	STK621-140B-E	3-phase inverter motor driver	IRAMS10UP60B
	STR-A6059H	PWM type switching power supply with low noise and low stand-by power	C0DAZYY00028
	STR-F6676	Off-line quasi-resonant flyback switching type voltage regulator for TV SMPS	C5HABZZ00080
	STR-W6735	Quasi-resonant primary switching regulator for TV SMPS	NTE7224
	STR-W6753	Off-line quasi-resonant flyback switching type regulator for TV SMPS	IRIS-W6753
	STR-W6756	Off-line quasi-resonant flyback switching type regulator for TV SMPS	IRIS-W6756
	TA8859AP	TV deflection stage with horizontal and vertical deflection bias distortion compensation	C1AA00000359
	TDA7480	10W class-D power audio amplifier with mute and stand-by	C1AA00000561
	TPS4100	Quadruple 100W BTL class-T power audio amplifier output stage with mute and sleep	C1AA00000561
