Friday, September 30, 2011

Block Diagram Ultrasound System: Portable

Block Diagram (SBD) for a portable ultrasound machine using TI’s TMS320 family of processors for beamforming, preprocessing, back-end processing tasks with interface to TI’s Analog Front Ends, pulsers, and output DAC’s.

Click here for the link:http://www.ti.com/solution/ultrasound_system_portable





Tuesday, September 27, 2011

Today There is Typhoon In Our Country

We are experiencing now a typhoon in our country in Philippines. Here in cavite, my place, we have a signal 1 and we have a medium rain falls and a little heavy gustiness of wind. But in northern part of our country where is the center of the typhoon experiencing heavy rains and heavy gustiness of winds which is signal number 3.



Thursday, September 22, 2011

Have you ever had an LED or other diode placed backwards? By us? By someone else? By yourself? We don't like it when that happens and we're sure you don't either. Screaming Circuits strives to place every component, from the largest, highest pin-count logic chip down to the smallest passive components, correctly every single time. A key element of that accuracy is our understanding of your board and the component markings. If you use surface mount diodes or LEDs, you probably understand the challenges involved in correctly and consistently indicating diode polarity. LEDs are usually cathode negative, while zeners and uni-directional TVS diodes can be cathode positive. Barrier diodes can be either orientation. It all depends on whether the diode is a rectifier, an LED, a uni-directional TVS, part of a daisy-chain and a host of other considerations. When you start looking at the CAD libraries, you not only have all the differences from that manufacturer, you may also have different markation schemes from each CAD package developer and from each library builder. Guidelines for diode polarity mark silk-screening – “A” for Anode or “C” for Cathode.

Click here for more details: http://blog.screamingcircuits.com/files/led_markation_guidelines.pdf




Design News Magazine September 2011 Issue




INSIDE THE SEPTEMBER ISSUE:
  • Prius Plugs into a New Era
    Small battery, fast recharge, and low cost are the keys to Toyota's "less is more" strategy of electrification.
  • Design Tools Get the Human Touch
    Graphics-rich mobile devices, greater processing power, and consumers' continuing push for simplicity are remaking the design tool experience to be lesss technology centric and more focused on human-centered design.
  • Design Revolution
    Low-cost 3D printers are rapidly changing the design process.
  • Click here for the link: http://www.nxtbook.com/nxtbooks/ubm/designnews_201109/#/0


Friday, September 16, 2011

The World's Longest Binoculars

http://www.hammacher.com/Product/78069?source=EMM12711&cm_ven=WC&cm_cat=20110915_EMM127&cm_pla=REQ&cm_ite=78069_The/%20144X%20Zoom%20Binoculars


Saturday, September 10, 2011

Manila International Bookfair

This coming September 14 to 18 there is an international book fair. I hope i can go there to look for some helpful books. Like in electronics subject. If in your country there is an event like these try to visit to expand your knowledge.


Here are the top 10 energy that consume the most energy.

Here are a few strategies:
Use a switchable power strip to pull the plug on clusters of computer or video products.
Buy low standby products if you can find them. Don't ask a salesperson though because they probably won't know. Better to look for ENERGY STAR products, which are tested for profligate reliance on standby power.
Buy a low-cost watt-meter, measure the devices in your home and take targeted action.
If all else fails, pull the plug, but be careful not to get electrocuted in the process.
Here are the top 10 energy that consume the most energy.
Photo: Business Wire
No. 1: Set-Top Box*
Average Watts While Off: 28.286
Average Watts While On: 30.198
*Average includes DVR, digital cable, digital cable with DVR, satellite, satellite with DVR.
No. 2: Notebook Computer
Average Watts While Off: 8.90
Average Watts While On: 29.48

Photo: Wikipedia
No. 3: Inkjet/Multifunction Fax
Average Watts While Off: 5.31/5.26
Average Watts While On: 6.22/9.16



No. 4: DVD/VCR
Average Watts While Off: 5.04
Average Watts While On: 13.51

Photo: Wikipedia
No. 5: VCR
Average Watts While Off: 4.68
Average Watts While On: 7.77


No. 6: Central Heating Furnace
Average Watts While Off: 4.21
Average Watts While On: 339.71

Photo: Wikipedia
No. 7: Cable Modem
Average Watts While Off: 3.84
Average Watts While On: 6.25


No. 8: Multi-Function Laser Device
Average Watts While Off: 3.12
Average Watts While On: 46.98

Photo: AP
No. 9: Cordless Phone With Answering Machine
Average Watts While Off: 2.92
Average Watts While On: 3.53


No. 10: Desktop Computer
Average Watts While Off: 2.84
Average Watts While On: 73.97

Source click here: http://finance.yahoo.com/family-home/article/113465/top-energy-consuming-items-forbes


Friday, September 9, 2011

Three Outlet Surge Protector with 2 USB Chargers

EMF-3
A NEW 3-outlet Surge Protector with additional 2 USB chargers has just been added to the ECG line of Surge
Protectors!

Features:
  • Converts one grounded outlet of similar rating to 3 grounded and protected outlets
  • 2 USB charger outlets
  • Adapter spaced outlets
  • LED Indicates Active Surge Protection
  • 1050 Joule Rating
  • cULus Approved
  • Appropriate for use in homes, offices, businesses and more
  • Blister packaged

USB Chargers For:
Cameras
Cell Phones
Tablets
MP3 Players
and more!

Plug-In Protection For:
Office
Industrial
Residential
Institutional/Industrial

Click here for link pdf: http://www.nteinc.com/ecgproducts/pdf/surge_suppressor.pdf

Thursday, September 8, 2011

A generic DMM test and calibration strategy

The Digital Multimeter or DMM is one of the most widely used electrical measurement
instruments and provides electrical traceability to many industrial users. However, it is
the nature of measurement products that they require regular checks to ensure that
they operate not only in a functional sense, but also within their specifications. Such
regular checks are known as calibrations and require a certain amount of knowledge
of DMM technology in order to calibrate them effectively. This application note seeks
to identify the important functional and calibration parameters and to offer a generic
guidance strategy for their routine verification. Click here for the link:http://cancomdigital.com/resourcecenter/assetsrc/Fluke_GenericDMMTest.pdf


High End LCD Wide Screen Sunlight Readable

    Features:
  • Engineered for All-Weathers even in direct sunlight
  • 32" Very Bright Active Matrix Sunlight Readable TFT Display, Indoors: 850 nits (cd/m2) Outdoors: 1400 nits (cd/m2)
  • Machined NEMA 4 (IP65) Rated, Black Powder Coated, Very Rugged Aluminum Gasket Sealed Enclosure
  • Various Mounting Configurations: Ceiling or Wall Mount
  • Orientation: Portrait or Landscape
  • Optical Bonding of Anti-Reflective Protective Window Directly to the Front Surface of the LCD Face (VBOND)
  • Integration of light management & optimization films
  • A multitude of Video Inputs: HD15(F), DVI-D Pin, Composite BNC, Mini Din (S-video)
  • High Contrast Ratio (4000:1) & Definition, Outstanding Vivid Color & Image Quality
  • Wide Color Gamut
  • Very Wide Viewing Angles: 88° / 88° / 88° / 88°
  • 16.8 million colors
  • Energy Efficient, Low Power Consumption
  • High Environmental Performance and Reliability
  • 1366 x 768 Resolution
  • Advanced Thermal Management System
  • Wide Operational Temperature Range, -40°C to +60°C (-40°F to +140°F)
  • Infrared Handheld Remote Control
  • RoHS Compliant
  • Engineered and Manufactured by VarTech Systems, an ISO 9001 Registered Company
  • Engineered, Fabricated and Assembled in the USA Made in America
  • Two (2) Year Warranty
    Optional Features:
  • Impact Resistant Protective Windows
  • KVM Extender
  • Integrated Computer
  • Media Player
  • Vandal Protection Window
  • OSD Control through RS-232
  • Internal TV Tuner
  • CCTV Multiplexer
  • Ceiling or Wall Mounts
  • Custom Mounts
  • Touch Screen
  • Alternate Connector Locations
  • Private Label for OEM/VAR Applications
Our rugged industrial computer monitors offer a variety of configurations and are ideal for HMI applications in a variety of harsh environments. Click here :http://www.vartechsystems.com/products/model/VT320VHB.asp
